Model
KBS30
Pump Set
Suck Grade(m)
6
Lift(m)
24
Volume of Flow(m3/h)
60
Diameter of in&out Pipe(mm/inch)
75/3.0
Engine
Type
KB168F
4-stroke/air cooling/single cylinder/ OHV horizontal shaft
Displacement(cc)
196
Max. Output(kw)
4.8
Ignition Mode
Transistorized Magneto
Starting Mode
Recoil Start
Fuel Tank Capacity(l/gal.)
3.6/0.95
Continuous Work Time(h)
2.0
Noise Level(7m)(dB)
68
Dimensions
Dimensions(L×W×H)(mm/inch)
520*430*440/21*17*18
Dry Weight(kg/lb)
30/67
20FT Qty
275
40FT Qty
500
40HQ Qty
575
