Model
HP6500GF
Generator
Frequency(Hz)
50
60
Rated AC Output Power (kw)
5.0
5.5
Max. AC Output Power (kw)
6.0
1-Phase Rated AC Voltage(V)
110;220;110/220
DC Output
12V—8.3A
Power Factor(cos∮)
1.0
Engine
KB188F
Type
4-stroke/air cooling/single cylinder/OHV horizontal shaft
Displacement(cc)
389
Ignition Mode
Transistorized Magneto
Starting Mode
Recoil Start/Electric start/Remote Start
Max. Output(hp/rpm)
9/3600
Fuel Tank Capacity(l/gal.)
25/6.6
Oil Capacity(l/gal.)
1.1/0.29
Continuous Work Time(h)
13
10
Noise Level(7m)(dB)
69
Options
Electric Start System
√
4-wheel Vehicle Set
Double Voltage Switch
Remote Control System
Non-blackout Standby Control System
Digital Overload Protection Control System
Dimensions
Dimensions(L×W×H)(mm/inch)
700*550*570/28*20*23
Dry Weight(kg/lb)
63/139
20FT Qty
128
40FT Qty
268
40HQ Qty
